GENERAL SPECIFICATIONS
* EN 54-7 and EN54-5 Certified
* Detects smoke particles in the environment via Light Scatter principle and generates alarm
* Detector is A2S class and gives alarm at 55oC
* Addressability with TFCM-1801 Device Programming-Addressing module (optional)
* 240 Detector addressing in each loop
* 2 LED indicators enabling viewing from all directions
* Two different colors of indication by LEDs to individually display error and alarm conditions (Blue/Red)
* LEDs which indicate operation of detector can be optionally deactivated
* 3 different detection sensitivity adjustable from the control panel and configuration software (High, Medium, Low)
* Metallic cage and special protection circuit elements to increase EMC and LVD resistance and to prevent associated faulty alarms
* Special software algorithms to eliminate sudden dust, smoke, etc. external factors that may result in faulty alarms
* Metallic cage preventing entrance of bugs, flies and foreign objects into detector sensing chamber
* Adaptive protection preventing faulty alarms by sampling the environment continuously
* Advanced pollution algorithm that continuously measures pollution level and warning the user from detector and panel screen for stabile and accurate operation
* Day/Night operation modes that can be programmed automatically or by user for alarm verification
* Insert type contact structure eliminating non-contact problems
* Parallel indicator light connection option
* Easy to clean smoke chamber
* Aesthetic and elegant design fits any environment
* Label apparatus that can be installed to the bottom of detector for easy viewing of detector address by technical personnel (Optional)
