General Features
* EN 54-2 and EN 54-4 Certified
* Fully monitorable 8 zone capacity
* Maximum 32 units ofTEKNIM Conventional fire detectors can be connected to each zone
* User-friendly, easy to manage indicator panel
* Separate fire and error LEDs for each zone
* Smart charging system extending battery life
* Smart protection system that prevents direct starting of device from battery for security reasons
* Walk-through test function that can be performed by a single person
* Disabling of each zone individually
* lnspection feature via siren outputs and zone inputs line end resistances against faulty connections
* 2 X 500mA si ren outputs allowing maximum 60 Teknim TFS-3192 siren connection
* 24 VDC 500mA external supply output with automatic fuse (AUX)
* 1 N C/NO fire relay (8utton ala rm, detector ala rm, etc.)
* 1 N C/NO error relay (Energy failure, zone failure, battery failure etc.)
* Key system to define intervention authority level
* Removable cover design enabling easy installation
* Switch Mode Power Supply (SMPS) (27.6VDC SMPS 1.5Ah Automatic Fuse)
